Jasic MIG200PFC N2S52 MIG/MAG welding machine

MIG200 PFC N2S52

Features:

– Robust and industrial look with ergonomic design

–
ClearVision –

Technology

– Intelligent synergy control

– Large adjustable welding current range

– Professional mode

– TIG-Liftarc

– MIG tacking function with consistent and efficient performance

– Flexible remote controls, optional (radio or wired)

– Power factor correction (PFC), generator suitability

– One-touch reset and auto standby mode

– Compatible with all common digital MIG torches, spool guns and push-pull torches

– Coil compartment with integrated LED lighting including storage compartment

– Automatically controlled machine fan

– Transport trolley with holder for gas cylinder

– High user safety thanks to voltage reduction (VRD)

– Protection of all important electronic power components through integrated overcurrent and overheating protection

Input voltage		AC95～265 V, 50/60 Hz; AC 230V
Open circuit voltage		68 V
MIG	Power consumption	32.8 A
	Nominal input power	7.5 kVA
	Welding current setting range	30～200 A
	Duty cycle	30%
	Wire speed	2～16 m/min
	Coil diameter	D300
MMA	Power consumption	24.8 A
	Nominal input power	5.7 kVA
	Welding current setting range	20～180 A
	Duty cycle	30%
TIG	Power consumption	19.3 A
	Rated input voltage capacity	4.4 kVA
	Welding current setting range	5～200 A
	Duty cycle	30%
Efficiency		<80%
Power factor		0.99
Power consumption in idle state		＜50 W
Protection class		IP23S
Insulation class		H
Dimensions (L×W×H)		920×480×755 mm
Weight		41.9 kg

Take a look at our YouTube channel

INFO DELIVERY, THE JASIC DEVICES ARE AVAILABLE FROM MID FEB.23 DELIVERABLE
